Product Description

Ethernet RJ45 Connectors and LAN Transformers
Magnetic Ethernet Rj45 Fastjacks Cat5 Modular Pcb Vertical Rj45 Jack Connector With Transformer
Products Description
Item RJ45 Female Connector
Part Status Active
Connector Type Jack
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Application-Lan Ethernet(NoN PoE)
Number of Ports 1x1 Port
Speed 10/100/1000 Base-T
Latch Down/Up
Cores per Port 4
Orientation 90° Angle (Right)
PCB Mount Angle SIDE ENTRY
Shield EMI Tabs Without/With
LED Option Green/Yellow
PCB FR4
PCB Retaining Post T POST
Temperature 0℃ TO 70℃ / -40℃ TO 85℃
Bst Circuit Yes
AutomDX YES
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Turns Ratio RX/TX 1CT:1CT
Configuration RX/TX T,C
RJ45 Connector Side View
RJ45 Connector Top View
RJ45 Connector Pin Details
RJ45 Connector Packaging
RJ45 Connectors Series Grid
Production Banner
Product Detail Dimension Diagram
PCB Footprint Dimensions
Connector Internal Schematic
Electrical Performance Testing
Solder Ability Standards
Reflow Temperature Profile
Company Profile
Established in 1997, we are a professional designer and manufacturer in magnetic telecom and networking components, offering an extensive line of state-of-the-art catalog products as well as custom capabilities.
As a global supplier of magnetic telecom and networking components to OEMs, contract manufacturers, and CEMs, we serve more than 10,000+ customers in over 200 countries. By building multi-warehouse systems in key areas and continuously increasing inventory, we are committed to becoming the world's leading Ethernet RJ45 connector and LAN transformer provider.
Manufacturing Plant Exterior
Automated Production Lines
FAQ
Are you a factory or trading company?
We are a specialized manufacturer of magnetic telecom and networking components, including RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
Can I get a sample before mass production?
Yes, we can offer you free samples to test the quality, but the shipping fee needs to be covered by the customer.
What is your delivery time?
Items in stock are ready to ship. For mass production orders, the delivery time is approximately 15 to 30 days.
What after-service can you offer?
We provide a one-year guarantee period along with 24-hour online technical support.
Can you accept OEM/ODM orders?
Yes, we accept custom orders. Please send your requirements to us for a detailed discussion.
What is your advantage?
We have 19 years of production experience and have been a trusted partner to global industry leaders for many years.
