Multiple Mode 850nm 400G QSFP-DD SR8 100m MTP/MPO-16 APC MMF Optical Transceiver Module

Product Description

Multiple Mode 850nm 400G QSFP-DD SR8 100m MTP/MPO-16 APC MMF Optical Transceiver Module
Products Description
Item Fiber Optical Modules
Part Status Active
Form Factor QSFP-DD
Max Data Rate 400Gbps
Max Cable Distance 70m@OM3 / 100m@OM4
Wavelength 850nm
Connector MTP/MPO-16 (APC)
Media MMF
Optical Component VCSEL/PIN
TX Power -6 ~ 4dBm
RX Power -7.9 ~ 4dBm
Modulation 8x 50G PAM4
Powerbudget 1.9dB
Power Consumption ≤10W
Extinction Ratio 3dB
DDM/DOM DDM Supported
Commercial Temperature Range 0 to 70°C (32 to 158°F)
Warranty 5 Years
Sample Available
Protocols IEEE 802.3cd, QSFP-DD MSA, CMIS 4.0
VIEW OUR SOLUTION
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module. We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
Optical Transceiver Module Structure
Transceiver Module Details 1
Transceiver Module Details 2
Transceiver Dimension Diagram
Optical Modules Categories Map
Transceiver Application Design
Interface Port Detail
Transceiver Internal Components
Related Products SFP Cage
SFP Cage Showcase
Why Choose Us
Why Choose Us Detail 1
Why Choose Us Detail 2
Why Choose Us Detail 3
Why Choose Us Detail 4
Company Profile
We are a specialized manufacturer of magnetic telecom and networking components, certificated by ISO9001:2000, ROSH, REACH, CE and UL, owning advanced manufacturing facilities and testing equipment.

Established in 1997, we currently have around 2000 staff. With an abundant production capacity of 3000K per month, we are able to deliver products within a short timeframe.

Moreover, we provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks. The range also offers high-speed optical interconnection solutions for cloud computing and ultra-broadband networks. Utilizing the latest optoelectronics technologies, we develop, manufacture, and sell products worldwide.
Production Workshop
Testing Equipment
FAQ
1. Are you a factory or trading company?
We are a specialized manufacturer of magnetic telecom and networking components, such as RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
2. Can I get a sample before mass production?
Yes, we can offer you free samples to test the quality, but the shipping fee should be paid by your side.
3. What is your delivery time?
Ready to ship for stock items, and 15-30 days for mass production.
4. What after-service can you offer?
We provide a one-year guarantee period along with 24-hour online technical support.
5. Can you accept OEM/ODM orders?
Yes, please send an inquiry to us so that we can have a detailed discussion about your specific requirements.
6. What is your advantage?
We have over 19 years of dedicated production experience in the industry, delivering high-performance components globally.
